Work Turbochargers G4S-5857

The G4S-5857 represents the latest generation in Work Turbocharger performance — engineered for enthusiasts who demand efficiency, durability, and fast response. A refined variant of our Grand National–specific turbo, this model adds new housing coatings, enhanced balancing, a new variant of our 58mm compressor wheel, and multiple bearing configurations to suit a wide range of builds and budgets.


Standard with This New Generation

  • Ceramic-Coated Bearing Housing – Enhances heat resistance and improves durability under extreme operating conditions.

  • Three-Stage Balancing Process – Precision-balanced for smoother operation, reduced vibration, and extended bearing life.

  • Built Entirely from New Components – No remanufactured parts; every turbo is assembled from 100% new materials.

  • Blueprinted and Improved Bearing Structure – Optimized internal clearances and upgraded bearing design for increased reliability and efficiency.


Bearing Options

  • Dual Ceramic Ball Bearings – Maximum efficiency, faster spool, and improved transient response.

  • Hydrodynamic Journal Bearings – Proven durability and cost-effective performance.


Compressor Specifications

  • Compressor Wheel Exducer: 76 mm

  • Compressor Wheel Inducer: 58 mm

  • Trim: 58

  • A/R: 0.70

  • Maximum Flow Rate: 71 lb/min

Compressor Housing Connections:

  • Inlet: 4.0" Hose Coupler

  • Outlet: 2.5" Hose Coupler

  • Built-in anti-surge machining with improved shroud design for enhanced surge resistance


Turbine Specifications

  • Turbine Wheel Inducer: 65 mm

  • Turbine Wheel Exducer: 57 mm

  • Trim: 76

  • Housing: T3 Inlet, 4-Bolt External Wastegate Outlet

  • Available A/R Options: Customizable upon order


Key Features

  • Ported shroud design for exceptional surge resistance

  • Choice of Hydrodynamic or Dual Ceramic Ball Bearing systems

  • Forged, fully machined billet compressor wheel

  • Lightweight aluminum backplate for reduced rotating mass

  • Built and balanced to exacting performance standards
